0成本利用CloudFlare网站的Workers搭建VLESS 永久免费节点有邮箱就可以

前言

近期很火的利用 CloudFlare Workers 搭建 VLESS 节点，支持自定义伪装网页，可以 CDN 自选域名

注册 CloudFlare

相信很多人都有 CloudFlare 帐户，使用QQ邮箱或者其他邮箱都可以，用于注册 CloudFlare账户

cloudflare官网：cloudflare.com

CloudFlare Workers vless 代码部署

注意：只需要更改 UUID, 添加 proxyIP 地址即可

// <!--GAMFC-->version base on commit 43fad05dcdae3b723c53c226f8181fc5bd47223e, time is 2023-06-22 15:20:02 UTC<!--GAMFC-END-->.
// @ts-ignore
import { connect } from 'cloudflare:sockets';
// How to generate your own UUID:
// [Windows] Press "Win + R", input cmd and run:  Powershell -NoExit -Command "[guid]::NewGuid()"
let userID = 'd342d11e-d424-4583-b36e-524ab1f0afa4';
let proxyIP = '';
if (!isValidUUID(userID)) {
  throw new Error('uuid is not valid');
}
export default {
  /**
   * @param {import("@cloudflare/workers-types").Request} request
   * @param {{UUID: string, PROXYIP: string}} env
   * @param {import("@cloudflare/workers-types").ExecutionContext} ctx
   * @returns {Promise<Response>}
   */
  async fetch(request, env, ctx) {
    try {
      userID = env.UUID || userID;
      proxyIP = env.PROXYIP || proxyIP;
      const upgradeHeader = request.headers.get('Upgrade');
      if (!upgradeHeader || upgradeHeader !== 'websocket') {
        const url = new URL(request.url);
        switch (url.pathname) {
          case '/':
            return new Response(JSON.stringify(request.cf), { status: 200 });
          case `/${userID}`: {
            const vlessConfig = getVLESSConfig(userID, request.headers.get('Host'));
            return new Response(`${vlessConfig}`, {
              status: 200,
              headers: {
                "Content-Type": "text/plain;charset=utf-8",
              }
            });
          }
          default:
            return new Response('Not found', { status: 404 });
        }
      } else {
        return await vlessOverWSHandler(request);
      }
    } catch (err) {
      /** @type {Error} */ let e = err;
      return new Response(e.toString());
    }
  },
};
/**
 *
 * @param {import("@cloudflare/workers-types").Request} request
 */
async function vlessOverWSHandler(request) {
  /** @type {import("@cloudflare/workers-types").WebSocket[]} */
  // @ts-ignore
  const webSocketPair = new WebSocketPair();
  const [client, webSocket] = Object.values(webSocketPair);
  webSocket.accept();
  let address = '';
  let portWithRandomLog = '';
  const log = (/** @type {string} */ info, /** @type {string | undefined} */ event) => {
    console.log(`[${address}:${portWithRandomLog}] ${info}`, event || '');
  };
  const earlyDataHeader = request.headers.get('sec-websocket-protocol') || '';
  const readableWebSocketStream = makeReadableWebSocketStream(webSocket, earlyDataHeader, log);
  /** @type {{ value: import("@cloudflare/workers-types").Socket | null}}*/
  let remoteSocketWapper = {
    value: null,
  };
  let udpStreamWrite = null;
  let isDns = false;
  // ws --> remote
  readableWebSocketStream.pipeTo(new WritableStream({
    async write(chunk, controller) {
      if (isDns && udpStreamWrite) {
        return udpStreamWrite(chunk);
      }
      if (remoteSocketWapper.value) {
        const writer = remoteSocketWapper.value.writable.getWriter()
        await writer.write(chunk);
        writer.releaseLock();
        return;
      }
      const {
        hasError,
        message,
        portRemote = 443,
        addressRemote = '',
        rawDataIndex,
        vlessVersion = new Uint8Array([0, 0]),
        isUDP,
      } = processVlessHeader(chunk, userID);
      address = addressRemote;
      portWithRandomLog = `${portRemote}--${Math.random()} ${isUDP ? 'udp ' : 'tcp '
        } `;
      if (hasError) {
        // controller.error(message);
        throw new Error(message); // cf seems has bug, controller.error will not end stream
        // webSocket.close(1000, message);
        return;
      }
      // if UDP but port not DNS port, close it
      if (isUDP) {
        if (portRemote === 53) {
          isDns = true;
        } else {
          // controller.error('UDP proxy only enable for DNS which is port 53');
          throw new Error('UDP proxy only enable for DNS which is port 53'); // cf seems has bug, controller.error will not end stream
          return;
        }
      }
      // ["version", "附加信息长度 N"]
      const vlessResponseHeader = new Uint8Array([vlessVersion[0], 0]);
      const rawClientData = chunk.slice(rawDataIndex);
      // TODO: support udp here when cf runtime has udp support
      if (isDns) {
        const { write } = await handleUDPOutBound(webSocket, vlessResponseHeader, log);
        udpStreamWrite = write;
        udpStreamWrite(rawClientData);
        return;
      }
      handleTCPOutBound(remoteSocketWapper, addressRemote, portRemote, rawClientData, webSocket, vlessResponseHeader, log);
    },
    close() {
      log(`readableWebSocketStream is close`);
    },
    abort(reason) {
      log(`readableWebSocketStream is abort`, JSON.stringify(reason));
    },
  })).catch((err) => {
    log('readableWebSocketStream pipeTo error', err);
  });
  return new Response(null, {
    status: 101,
    // @ts-ignore
    webSocket: client,
  });
}
/**
 * Handles outbound TCP connections.
 *
 * @param {any} remoteSocket
 * @param {string} addressRemote The remote address to connect to.
 * @param {number} portRemote The remote port to connect to.
 * @param {Uint8Array} rawClientData The raw client data to write.
 * @param {import("@cloudflare/workers-types").WebSocket} webSocket The WebSocket to pass the remote socket to.
 * @param {Uint8Array} vlessResponseHeader The VLESS response header.
 * @param {function} log The logging function.
 * @returns {Promise<void>} The remote socket.
 */
async function handleTCPOutBound(remoteSocket, addressRemote, portRemote, rawClientData, webSocket, vlessResponseHeader, log,) {
  async function connectAndWrite(address, port) {
    /** @type {import("@cloudflare/workers-types").Socket} */
    const tcpSocket = connect({
      hostname: address,
      port: port,
    });
    remoteSocket.value = tcpSocket;
    log(`connected to ${address}:${port}`);
    const writer = tcpSocket.writable.getWriter();
    await writer.write(rawClientData); // first write, nomal is tls client hello
    writer.releaseLock();
    return tcpSocket;
  }
  // if the cf connect tcp socket have no incoming data, we retry to redirect ip
  async function retry() {
    const tcpSocket = await connectAndWrite(proxyIP || addressRemote, portRemote)
    // no matter retry success or not, close websocket
    tcpSocket.closed.catch(error => {
      console.log('retry tcpSocket closed error', error);
    }).finally(() => {
      safeCloseWebSocket(webSocket);
    })
    remoteSocketToWS(tcpSocket, webSocket, vlessResponseHeader, null, log);
  }
  const tcpSocket = await connectAndWrite(addressRemote, portRemote);
  // when remoteSocket is ready, pass to websocket
  // remote--> ws
  remoteSocketToWS(tcpSocket, webSocket, vlessResponseHeader, retry, log);
}
/**
 *
 * @param {import("@cloudflare/workers-types").WebSocket} webSocketServer
 * @param {string} earlyDataHeader for ws 0rtt
 * @param {(info: string)=> void} log for ws 0rtt
 */
function makeReadableWebSocketStream(webSocketServer, earlyDataHeader, log) {
  let readableStreamCancel = false;
  const stream = new ReadableStream({
    start(controller) {
      webSocketServer.addEventListener('message', (event) => {
        if (readableStreamCancel) {
          return;
        }
        const message = event.data;
        controller.enqueue(message);
      });
      // The event means that the client closed the client -> server stream.
      // However, the server -> client stream is still open until you call close() on the server side.
      // The WebSocket protocol says that a separate close message must be sent in each direction to fully close the socket.
      webSocketServer.addEventListener('close', () => {
        // client send close, need close server
        // if stream is cancel, skip controller.close
        safeCloseWebSocket(webSocketServer);
        if (readableStreamCancel) {
          return;
        }
        controller.close();
      }
      );
      webSocketServer.addEventListener('error', (err) => {
        log('webSocketServer has error');
        controller.error(err);
      }
      );
      // for ws 0rtt
      const { earlyData, error } = base64ToArrayBuffer(earlyDataHeader);
      if (error) {
        controller.error(error);
      } else if (earlyData) {
        controller.enqueue(earlyData);
      }
    },
    pull(controller) {
      // if ws can stop read if stream is full, we can implement backpressure
      // https://streams.spec.whatwg.org/#example-rs-push-backpressure
    },
    cancel(reason) {
      // 1. pipe WritableStream has error, this cancel will called, so ws handle server close into here
      // 2. if readableStream is cancel, all controller.close/enqueue need skip,
      // 3. but from testing controller.error still work even if readableStream is cancel
      if (readableStreamCancel) {
        return;
      }
      log(`ReadableStream was canceled, due to ${reason}`)
      readableStreamCancel = true;
      safeCloseWebSocket(webSocketServer);
    }
  });
  return stream;
}
// https://xtls.github.io/development/protocols/vless.html
// https://github.com/zizifn/excalidraw-backup/blob/main/v2ray-protocol.excalidraw
/**
 *
 * @param { ArrayBuffer} vlessBuffer
 * @param {string} userID
 * @returns
 */
function processVlessHeader(
  vlessBuffer,
  userID
) {
  if (vlessBuffer.byteLength < 24) {
    return {
      hasError: true,
      message: 'invalid data',
    };
  }
  const version = new Uint8Array(vlessBuffer.slice(0, 1));
  let isValidUser = false;
  let isUDP = false;
  if (stringify(new Uint8Array(vlessBuffer.slice(1, 17))) === userID) {
    isValidUser = true;
  }
  if (!isValidUser) {
    return {
      hasError: true,
      message: 'invalid user',
    };
  }
  const optLength = new Uint8Array(vlessBuffer.slice(17, 18))[0];
  //skip opt for now
  const command = new Uint8Array(
    vlessBuffer.slice(18 + optLength, 18 + optLength + 1)
  )[0];
  // 0x01 TCP
  // 0x02 UDP
  // 0x03 MUX
  if (command === 1) {
  } else if (command === 2) {
    isUDP = true;
  } else {
    return {
      hasError: true,
      message: `command ${command} is not support, command 01-tcp,02-udp,03-mux`,
    };
  }
  const portIndex = 18 + optLength + 1;
  const portBuffer = vlessBuffer.slice(portIndex, portIndex + 2);
  // port is big-Endian in raw data etc 80 == 0x005d
  const portRemote = new DataView(portBuffer).getUint16(0);
  let addressIndex = portIndex + 2;
  const addressBuffer = new Uint8Array(
    vlessBuffer.slice(addressIndex, addressIndex + 1)
  );
  // 1--> ipv4  addressLength =4
  // 2--> domain name addressLength=addressBuffer[1]
  // 3--> ipv6  addressLength =16
  const addressType = addressBuffer[0];
  let addressLength = 0;
  let addressValueIndex = addressIndex + 1;
  let addressValue = '';
  switch (addressType) {
    case 1:
      addressLength = 4;
      addressValue = new Uint8Array(
        vlessBuffer.slice(addressValueIndex, addressValueIndex + addressLength)
      ).join('.');
      break;
    case 2:
      addressLength = new Uint8Array(
        vlessBuffer.slice(addressValueIndex, addressValueIndex + 1)
      )[0];
      addressValueIndex += 1;
      addressValue = new TextDecoder().decode(
        vlessBuffer.slice(addressValueIndex, addressValueIndex + addressLength)
      );
      break;
    case 3:
      addressLength = 16;
      const dataView = new DataView(
        vlessBuffer.slice(addressValueIndex, addressValueIndex + addressLength)
      );
      // 2001:0db8:85a3:0000:0000:8a2e:0370:7334
      const ipv6 = [];
      for (let i = 0; i < 8; i++) {
        ipv6.push(dataView.getUint16(i * 2).toString(16));
      }
      addressValue = ipv6.join(':');
      // seems no need add [] for ipv6
      break;
    default:
      return {
        hasError: true,
        message: `invild  addressType is ${addressType}`,
      };
  }
  if (!addressValue) {
    return {
      hasError: true,
      message: `addressValue is empty, addressType is ${addressType}`,
    };
  }
  return {
    hasError: false,
    addressRemote: addressValue,
    addressType,
    portRemote,
    rawDataIndex: addressValueIndex + addressLength,
    vlessVersion: version,
    isUDP,
  };
}
/**
 *
 * @param {import("@cloudflare/workers-types").Socket} remoteSocket
 * @param {import("@cloudflare/workers-types").WebSocket} webSocket
 * @param {ArrayBuffer} vlessResponseHeader
 * @param {(() => Promise<void>) | null} retry
 * @param {*} log
 */
async function remoteSocketToWS(remoteSocket, webSocket, vlessResponseHeader, retry, log) {
  // remote--> ws
  let remoteChunkCount = 0;
  let chunks = [];
  /** @type {ArrayBuffer | null} */
  let vlessHeader = vlessResponseHeader;
  let hasIncomingData = false; // check if remoteSocket has incoming data
  await remoteSocket.readable
    .pipeTo(
      new WritableStream({
        start() {
        },
        /**
         *
         * @param {Uint8Array} chunk
         * @param {*} controller
         */
        async write(chunk, controller) {
          hasIncomingData = true;
          // remoteChunkCount++;
          if (webSocket.readyState !== WS_READY_STATE_OPEN) {
            controller.error(
              'webSocket.readyState is not open, maybe close'
            );
          }
          if (vlessHeader) {
            webSocket.send(await new Blob([vlessHeader, chunk]).arrayBuffer());
            vlessHeader = null;
          } else {
            // seems no need rate limit this, CF seems fix this??..
            // if (remoteChunkCount > 20000) {
            //   // cf one package is 4096 byte(4kb),  4096 * 20000 = 80M
            //   await delay(1);
            // }
            webSocket.send(chunk);
          }
        },
        close() {
          log(`remoteConnection!.readable is close with hasIncomingData is ${hasIncomingData}`);
          // safeCloseWebSocket(webSocket); // no need server close websocket frist for some case will casue HTTP ERR_CONTENT_LENGTH_MISMATCH issue, client will send close event anyway.
        },
        abort(reason) {
          console.error(`remoteConnection!.readable abort`, reason);
        },
      })
    )
    .catch((error) => {
      console.error(
        `remoteSocketToWS has exception `,
        error.stack || error
      );
      safeCloseWebSocket(webSocket);
    });
  // seems is cf connect socket have error,
  // 1. Socket.closed will have error
  // 2. Socket.readable will be close without any data coming
  if (hasIncomingData === false && retry) {
    log(`retry`)
    retry();
  }
}
/**
 *
 * @param {string} base64Str
 * @returns
 */
function base64ToArrayBuffer(base64Str) {
  if (!base64Str) {
    return { error: null };
  }
  try {
    // go use modified Base64 for URL rfc4648 which js atob not support
    base64Str = base64Str.replace(/-/g, '+').replace(/_/g, '/');
    const decode = atob(base64Str);
    const arryBuffer = Uint8Array.from(decode, (c) => c.charCodeAt(0));
    return { earlyData: arryBuffer.buffer, error: null };
  } catch (error) {
    return { error };
  }
}
/**
 * This is not real UUID validation
 * @param {string} uuid
 */
function isValidUUID(uuid) {
  const uuidRegex = /^[0-9a-f]{8}-[0-9a-f]{4}-[4][0-9a-f]{3}-[89ab][0-9a-f]{3}-[0-9a-f]{12}$/i;
  return uuidRegex.test(uuid);
}
const WS_READY_STATE_OPEN = 1;
const WS_READY_STATE_CLOSING = 2;
/**
 * Normally, WebSocket will not has exceptions when close.
 * @param {import("@cloudflare/workers-types").WebSocket} socket
 */
function safeCloseWebSocket(socket) {
  try {
    if (socket.readyState === WS_READY_STATE_OPEN || socket.readyState === WS_READY_STATE_CLOSING) {
      socket.close();
    }
  } catch (error) {
    console.error('safeCloseWebSocket error', error);
  }
}
const byteToHex = [];
for (let i = 0; i < 256; ++i) {
  byteToHex.push((i + 256).toString(16).slice(1));
}
function unsafeStringify(arr, offset = 0) {
  return (byteToHex[arr[offset + 0]] + byteToHex[arr[offset + 1]] + byteToHex[arr[offset + 2]] + byteToHex[arr[offset + 3]] + "-" + byteToHex[arr[offset + 4]] + byteToHex[arr[offset + 5]] + "-" + byteToHex[arr[offset + 6]] + byteToHex[arr[offset + 7]] + "-" + byteToHex[arr[offset + 8]] + byteToHex[arr[offset + 9]] + "-" + byteToHex[arr[offset + 10]] + byteToHex[arr[offset + 11]] + byteToHex[arr[offset + 12]] + byteToHex[arr[offset + 13]] + byteToHex[arr[offset + 14]] + byteToHex[arr[offset + 15]]).toLowerCase();
}
function stringify(arr, offset = 0) {
  const uuid = unsafeStringify(arr, offset);
  if (!isValidUUID(uuid)) {
    throw TypeError("Stringified UUID is invalid");
  }
  return uuid;
}
/**
 *
 * @param {import("@cloudflare/workers-types").WebSocket} webSocket
 * @param {ArrayBuffer} vlessResponseHeader
 * @param {(string)=> void} log
 */
async function handleUDPOutBound(webSocket, vlessResponseHeader, log) {
  let isVlessHeaderSent = false;
  const transformStream = new TransformStream({
    start(controller) {
    },
    transform(chunk, controller) {
      // udp message 2 byte is the the length of udp data
      // TODO: this should have bug, beacsue maybe udp chunk can be in two websocket message
      for (let index = 0; index < chunk.byteLength;) {
        const lengthBuffer = chunk.slice(index, index + 2);
        const udpPakcetLength = new DataView(lengthBuffer).getUint16(0);
        const udpData = new Uint8Array(
          chunk.slice(index + 2, index + 2 + udpPakcetLength)
        );
        index = index + 2 + udpPakcetLength;
        controller.enqueue(udpData);
      }
    },
    flush(controller) {
    }
  });
  // only handle dns udp for now
  transformStream.readable.pipeTo(new WritableStream({
    async write(chunk) {
      const resp = await fetch('https://1.1.1.1/dns-query',
        {
          method: 'POST',
          headers: {
            'content-type': 'application/dns-message',
          },
          body: chunk,
        })
      const dnsQueryResult = await resp.arrayBuffer();
      const udpSize = dnsQueryResult.byteLength;
      // console.log([...new Uint8Array(dnsQueryResult)].map((x) => x.toString(16)));
      const udpSizeBuffer = new Uint8Array([(udpSize >> 8) & 0xff, udpSize & 0xff]);
      if (webSocket.readyState === WS_READY_STATE_OPEN) {
        log(`doh success and dns message length is ${udpSize}`);
        if (isVlessHeaderSent) {
          webSocket.send(await new Blob([udpSizeBuffer, dnsQueryResult]).arrayBuffer());
        } else {
          webSocket.send(await new Blob([vlessResponseHeader, udpSizeBuffer, dnsQueryResult]).arrayBuffer());
          isVlessHeaderSent = true;
        }
      }
    }
  })).catch((error) => {
    log('dns udp has error' + error)
  });
  const writer = transformStream.writable.getWriter();
  return {
    /**
     *
     * @param {Uint8Array} chunk
     */
    write(chunk) {
      writer.write(chunk);
    }
  };
}
/**
 *
 * @param {string} userID
 * @param {string | null} hostName
 * @returns {string}
 */
function getVLESSConfig(userID, hostName) {
  const vlessMain = `vless://${userID}@${hostName}:443?encryption=none&security=tls&sni=${hostName}&fp=randomized&type=ws&host=${hostName}&path=%2F%3Fed%3D2048#${hostName}`
  return `
################################################################
v2ray
---------------------------------------------------------------
${vlessMain}
---------------------------------------------------------------
################################################################
clash-meta
---------------------------------------------------------------
- type: vless
  name: ${hostName}
  server: ${hostName}
  port: 443
  uuid: ${userID}
  network: ws
  tls: true
  udp: false
  sni: ${hostName}
  client-fingerprint: chrome
  ws-opts:
    path: "/?ed=2048"
    headers:
      host: ${hostName}
---------------------------------------------------------------
################################################################
`;
}
